Architecture studio De Zwarte Hond has completed the Regulateur residential building in Grunobuurt, a post-war neighborhood that was built at a time of great housing shortages in the city of Groningen, in the north of the Netherlands.

The project arose from the decision to renovate the neighborhood on a large scale due to the poor condition of the homes that worsened the quality of life of the inhabitants to provide a happier and healthier life for the citizens.
The residential building designed by De Zwarte Hond is inspired by traditional "hofjes", almshouses built around courtyards. Regulateur is a staggered apartment block with between three and seven floors and with a central patio resulting from the incorporation of a garage in the neighborhood that allowed the patio to become a garden that all the homes face towards it.

The entrances give direct access to the garden and the ground floor, where a community bicycle storage and various social and commercial spaces are located, in addition to the living spaces. The building, characteristic of its brick construction, has a rhythmic façade due to the window openings that become loggias in the corners.


Regulateur by De Zwarte Hond. Photograph by Eva Bloem.


Project description by De Zwarte Hond

Regulateur is part of the Grunobuurt, a post-war neighbourhood that was built at a time of great housing scarcity. In 2004, it was decided to renovate the district on a major scale because the homes were in a poor state and quality of life was suffering as a result. We joined forces with housing corporation Nijestee and developing contractor Trebbein 2016, overhauling the construction, design and development process. Throughout the entire process, every aspect was transparent to all the parties and, where necessary, they were able to make adjustments together.

A remarkable and rhythmic façade
Regulateur is the sixth residential building in the renovated Grunobuurt area. The stepped apartment block ranges from three to seven storeys and has a beautifully rhythmic façade. The façade openings repeat around the block with accents at the corners supplied by loggias, and both the light and views increase the higher you go in the building. This is reflected in the façade pattern, featuring windows that are wider at the bottom which become progressively narrower towards the top.

Also eye-catching is the unusual brickwork, which seems to consist solely of a repeated header bond. Together with the Strating brick factory, we created a special brick for this. It has a mock joint, creating the appearance of a block bond that emphasizes the ‘fade’ pattern of the façade. We also made the brick less deep, 70 mm instead of the standard 100 mm. By combining this shallower brick with the occasional ordinary brick, we create a beautiful relief effect. As a whole, this not only results in a richly textured façade, but also saves a significant amount of material.


Regulateur by De Zwarte Hond. Photograph by Eva Bloem.

Community around a green courtyard
Parking has been solved centrally in the neighbourhood with a parking garage, which meant that the courtyard could become a garden. By positioning the outdoor spaces of all the housing types on this inner side, people live around the garden and everyone is facing it. Besides the greenery in the garden, vegetation will also grow along the façades on the inner sides of the building. In this peaceful green oasis, it will be easy and enjoyable to chat with the neighbours.

The generous entrances give direct access to the courtyard garden as well as to the communal bicycle storage facility. On the extra-high ground floor, as well as living spaces there is room for two social and commercial spaces that will enhance the neighbourhood. The building has solar panels on the roof.


Regulateur by De Zwarte Hond. Photograph by Eva Bloem.

Part of the urban regeneration
In addition to the Regulateur, De Zwarte Hond previously also designed the Typhoon and Tractie residential blocks in the Grunobuurt. We are also responsible for the new urban development plan in which we – in close consultation with residents – take the much-appreciated quality of ‘unity in diversity’ as a starting point.

The plan consists of an ensemble of eight closed brick building blocks that rise gradually and have height accents at various corners. The unity is achieved by unambiguous and recognizable building volumes and reinforced by rules for the design of the public space, the façade structure and the entrances of the building blocks. Variation is created in, for example, the profiles, detailing, types of brick and gutter heights.

The Regulateur in Groningen was designed by De Zwarte Hond and built by Trebbe as a commission from Nijestee.

More information

Label
Architects
Text
De Zwarte Hond. Lead architect.- Erik Roerdink.
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Collaborators
Text
Contractor.- Trebbe.
Technical Engineering.- Sweco.
Building Physics.- DGMR.
Landscape Architect.- Felixx Landscape Architects & Planners.
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Client
Text
Nijestee.
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Area
Text
9,942 sqm.
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Dates
Text
2019-2023.
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Location
Text
Groningen, The Netherlands.
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Manufacturers
Text
Ensel, Smit Bedum, Strating Baksteenindustrie.
+ + copy Created with Sketch.
- + copy Created with Sketch.
Label
Photography
Text
+ + copy Created with Sketch.
- + copy Created with Sketch.
De Zwarte Hond is a design agency for architecture, urban design and strategy with offices in Groningen, Rotterdam and Cologne. Through a combination of social commitment and craftsmanship, they create high-quality projects that are sensitive to their context, the needs of users and the vision of our customers.

Jurjen van der Meer (1953) is founder of De Zwarte Hond. After studying architecture, he worked for a number of years in Berlin, after which he founded Karelse Van der Meer architects together with Thon Karelse. In 1992 the Groningen office expanded with an office in Rotterdam, followed by Cologne, Germany in 2011. Since 2004, the agency is named De Zwarte Hond.

De Zwarte Hond has an overview of the various forces that play a role in a given place. They can calculate what will add value and improve the quality of life – for residents, the street, the neighbourhood and the city. Their designs are firmly grounded and speak the language of their environment, yet they display a subtle and unexpected individuality. This is the result of their details, their materials, their strong connection between inside and outside, and their smart and flexible use of space.

They design places, buildings and whole environments that look out of the ordinary. Conceived, rather than created; built to last and flexible enough to move on to a new phase of life in the future. Yet their places always touch the heart. Designing and realising interwoven spaces, that’s the essence of their office: they unite architecture and urban design.
